At Richter, we are committed to shaping the future of automotive education with cutting-edge training equipment. Our Automotive ABS EBD TCR System Trainer is a powerful learning tool designed to provide students and automotive professionals with a comprehensive, hands-on understanding of advanced braking systems, including ABS (Anti-lock Braking System), ASR (Anti-Slip Regulation), and ESP (Electronic Stability Program).
This trainer not only mimics real-world braking systems but also enables precise, live demonstrations of their operation. By simulating emergency braking scenarios and the interaction between various system components, it provides an unparalleled learning experience. Designed for automotive technicians, vocational schools, and repair centers, it’s the perfect tool for both theory-based learning and practical troubleshooting.
Key Features:
Real-World ABS/ASR/ESP Systems: Our trainer is based on authentic ABS/ASR/ESP braking systems, showcasing the composition and structural details of the braking system. This allows users to learn how the systems work in real-time, especially during emergency braking.
Interactive Brake Pedal Simulation: The training bench features a functional brake pedal that simulates the spring action felt during emergency braking. The ABS/ASR/ESP systems activate when the brake pedal is pressed, causing the front and rear brake discs to rotate slightly, providing an accurate demonstration of system behavior during an emergency stop.
Color-Coded Circuit and Hydraulic Diagrams: The training platform’s panel is equipped with vibrant, UV-printed circuit and hydraulic diagrams. Trainees can visually compare and analyze the system’s components, gaining a deeper understanding of the control system’s operation and working principles.
Real-Time Signal Detection: The training bench includes detection terminals, allowing direct measurement of various electrical signals from sensors and control units, such as voltage, resistance, current, and frequency. This feature helps students learn to diagnose and troubleshoot real-world issues in automotive systems.
Comprehensive Diagnostic Features: The platform is equipped with a fault indicator and diagnostic seat, which can connect to specialized or general vehicle decoders. This feature supports advanced functions such as ECU code reading, fault code clearing, data flow monitoring, and waveform analysis, crucial for mastering modern diagnostic techniques.
Pressure Gauge for Hydraulic Monitoring: A real-time pressure gauge displays hydraulic changes in the brake master cylinder and brake slave cylinders, enabling students to understand pressure fluctuations during braking and troubleshooting.
Robust Design with Mobility: The trainer features a sturdy steel frame with self-locking casters, making it easy to move and securely position in any training environment. Its durable, spray-treated surface ensures longevity and reliability for extensive use in educational settings.
Technical Specifications:
- Overall Dimension: 1500 x 1000 x 1700 mm (Length x Width x Height)
- External Power Supply: AC 220V ±10% 50Hz
- Operating Voltage: DC 12V
- Operating Temperature: -40℃ to +50℃
- Brake Slave Cylinder Pressure Gauge: 0-100 kg/psi
- Motor Power: 4KW/5.5KW
- Vacuum Pump: 370W with a pumping rate of 48L/min
- Noise Level: ≤68dB
- Mobile Casters: 100x50mm for easy mobility
- Panel Cabinet: Constructed from 1.5mm cold plate for enhanced durability
Value for Students:
- Hands-On Learning: Engage directly with an operational ABS/ASR/ESP braking system and experience how the systems behave during emergency braking, making it ideal for skill development and troubleshooting.
- Advanced Diagnostic Skills: Learn how to use diagnostic tools to read fault codes, analyze real-time data, and simulate faults to develop problem-solving skills.
- Comprehensive System Understanding: Study the entire system, including hydraulic, electronic, and mechanical components, and gain experience in both theoretical and practical diagnostics.
Value for Instructors:
- Realistic Teaching Tool: Demonstrate the functioning and structure of ABS, ASR, and ESP systems using real-world OEM parts for authentic learning experiences.
- Easy Fault Simulation: Simulate common faults and teach troubleshooting techniques by removing jumpers or using the integrated diagnostic system.
- Enhanced Training Efficiency: The robust, mobile design and easy-to-use control panel allow multiple students to engage with the system simultaneously, promoting collaborative learning.
- Safe Learning Environment: With removable panels protecting against hot and rotating parts, this trainer ensures safety while still providing easy access for maintenance and instructional purposes.
Why Choose Richter’s ABS EBD TCR System Trainer:
- Hands-On Learning: Equip students with practical experience in advanced automotive braking systems.
- Comprehensive Diagnostic Tools: Prepare students for real-world diagnostic tasks, improving their troubleshooting abilities.
- Durable, Easy-to-Use Design: The trainer’s robust frame and intuitive design ensure a long lifespan and seamless operation.
- Trusted by Industry Leaders: Richter works with leading automotive manufacturers and educational institutions to provide cutting-edge solutions for automotive training.
Optional Accessories (Sold Separately):
- Diagnostic Scan Tool TXB BIKE TEXA
- Diagnostic Oscilloscope TEXA Uniprobe
- Automotive Diagnostics Kit ADK5004D TiePie
- Foxwell Oscilloscope OS100
Transform the learning experience for your automotive students with the Automotive ABS EBD TCR System Trainer. Designed to meet the demands of modern automotive education, it offers both theoretical and practical training in one comprehensive platform.
