The Portable Whole Package Charge and Discharge Instrument is a versatile and efficient solution designed for electric vehicle (EV) battery module charging and discharging. This device, part of the BE-ET5060T series, is engineered to meet the demands of modern EV training and maintenance environments. Here are the key features and technical specifications of the product:
Key Features:
- High-Efficiency Energy Conversion: Utilizes a feed-back bi-directional AC/DC converter for efficient energy conversion.
- Portability: Compact design with easy portability, making it ideal for various training and operational settings.
- Versatility: Capable of converting DC voltage from battery modules to AC power for grid feedback and vice versa.
- User-Friendly: Designed for ease of use in educational and professional environments.
Technical Specifications:
| Indicator Items | Technical Parameters |
|---|---|
| Device Input | Input Voltage Range: 110~253Vac, frequency 50/60Hz±5Hz |
| Output Voltage Range: 10V~450Vdc | |
| Output Voltage Accuracy: ±0.1%FS | |
| Output Current Range: -60~60A | |
| Device Output | Output Current Accuracy: ±0.5%FS |
| Maximum Output Power: 6kW (110V mains input power halved) | |
| Voltage Ripple: ≤0.5%FS | |
| Current Ripple: ≤1%FS | |
| Maximum Efficiency: 90% | |
| Device Acquisition | Individual Voltage Acquisition Accuracy: ≤5mV |
| Temperature Acquisition Accuracy: ±1°C | |
| Power Quality | Power Factor: 0.99 |
| Current Harmonic: <5% | |
| Protective Functions | Grid-side Protection: AC over-voltage and under-voltage protection, over-current protection, short-circuit protection, etc. |
| Battery-side Protection: AC/DC over- and under-voltage protection, over-current protection, short-circuit protection, DC reverse connection protection. | |
| Working Environment | Altitude: ≤3000m |
| Environmental Temperature: -20 ~ 55°C | |
| Relative Humidity: 0 ~ 80%rh, non-condensing | |
| Cooling Method | Air Cooling |
| Dimensions | 250530290 mm |
| Weight | 17KG |
Applications:
- Educational Institutions: Ideal for universities and vocational schools offering EV training programs.
- Professional Training Centers: Suitable for automotive training centers and repair companies.
- EV Maintenance: Useful for technicians involved in the maintenance and repair of electric vehicles.
